Download our poster here: Louka & Primeau 2024
Poster presented at: the British Association for Forensic Anthropology (BAFA) Winter Conference 30th November 2024, Oxford
A systematic review on the application of Fractography in Forensic Anthropology and Trauma Analysis: Assessing the gap between Academia and Practice
Introduction: Fractography is the detailed study of fractured surfaces to understand the causes and mechanisms of material failure. Fractography helps identify the fracture types (classification), crack initiation points, crack propagation and stress during failure by analysing the topographic features of fracture surfaces. In forensic anthropology, bone fractography is a newly introduced method to the study of bone fractures and biomechanics This systematic review provides a comprehensive evaluation of the application of fractography in trauma analysis, the current state of research and level of experimental progress in the establishment of the technique.
Methods: Bibliographic research was conducted using Scopus, ProQuest, PubMed, and Web of Science with search terms ‘Fractography,’ ‘Forensic’, and ‘Anthropology’, and variations thereof. From 749 publications, titles and abstracts were screened, excluding duplicates, non-English or non-peer-reviewed papers, and studies not involving bone. Included papers applied fractography to human or animal (as human analogue) bones. The remaining full texts were reviewed, resulting in a final selection of 22 publications.
Preliminary results: The review shows the application of bone fractography across various trauma types; blunt force, projectile, and sharp-force trauma, using both human and animal remains. Imaging methods used were micro-CT, SEM and microscopy for observing fracture features. Experimental setups frequently apply three- and four-point bending to simulate trauma mechanics. However, no universal protocols or consistent experimental guidelines exist, restricting reproducibility and hindering cross-study comparisons. Additionally, while the identification of specific fracture features aids classification and interpretation, the technical demands of high-resolution imaging and the engineering origins of fractography present challenges in practical forensic contexts. The lack of accessible, standardised methods highlights a gap between academic advancements and routine forensic practice. To address these limitations, future efforts should prioritise cost-effective imaging, expanded training, and standardised protocols to support the reliable integration of fractography in forensic anthropology.
REFERENCES:
1] Blackburne et al. 2016. Biomechanical investigation of impact induced rib fractures of a porcine infant surrogate model. Journal of the Mechanical Behaviour of Biomedical Material, 62, pp. 588-598.
2] Braidotti et al. 1997. Scanning electron microscopy of human cortical bone failure surfaces. Journal of Biomechanics, 30(2), pp. 155-162.
3] Christensen & Decker. 2022. Fractography of Bone Using Reconstructed Computed Tomography (CT) Scans: A Case Report Series. Forensic Anthropology, 5(1), pp. 53-56.
4] Christensen & Hatch. 2019. Forensic fractography of bone using computed tomography (CT) scans. Journal of Forensic Radiology and Imaging, 18, pp. 37-39.
5] Christensen & Rickman. 2022. Cone cracking in human bone: A CT case review series. Forensic Imaging, 30, 200510.
6] Christensen et al. 2018. Forensic Fractography of Bone: A New Approach to Skeletal Trauma Analysis. Forensic Anthropology, 1(1), pp. 32-51.
7] Christensen et al. 2021. Forensic Fractography of Bone: Fracture Origins from Impacts, and an Improved Understanding of the Failure Mechanism Involved in Beveling. Forensic Anthropology, pp. 1-13.
8] Corondan & Haworth. 1986. A fractographic study of human long bone. Journal of Biomechanics, 19(3), pp. 207-218.
9] Duchene et al. 1977. Microscopic fracture aspects of impact tested human bones. Journal of Bioengineering, 1(4), pp. 197-207.
10] Edwards & Isa. 2024. Effects of kinetic energy and firearm‐to‐target distance on fracture behaviour in flat bones. Journal of Forensic Sciences, 69, pp. 400-414.
11] Emrith et al. 2022. Interpreting impact direction: applying fractography to the analysis of butterfly fractures produced by blunt force trauma. Australian Journal of Forensic Sciences, 54(1), pp. 26-41.
12] Isa et al. 2021. Investigating reverse butterfly fractures: An experimental approach and application of fractography. Forensic Science International, 325, 110899.
13] Kimura et al. 1977. Fractography of human intact long bone by bending. Zeitschrift fur Rechtsmedizin, 79, pp. 301-310.
14] L’Abbe et al. 2019. The Rorschach butterfly, understanding bone biomechanics prior to using nomenclature in bone trauma interpretations. Forensic Science International, 229, pp. 187-194.
15] Lillard & Christensen. 2020. Fractography of Long Bones with High-Velocity Projectile Trauma. Forensic Anthropology, 3, pp. 135-138.
16] Love & Christensen. 2018. Application of Bone Fractography to a Medical Examiner Sample: A Case Series. Forensic Anthropology, 1(4), pp. 221-227.
17] Skinner et al. 2023. Do bone elasticity and post-mortem interval affect forensic fractographic analyses? Journal of Forensic Sciences, 68, pp. 257-767.
18] Tomlin et al. 2000. Fractographic examination of racing greyhound central (navicular) tarsal bone failure surfaces using scanning electron microscopy. Calcified Tissue International, 67, pp. 260-266.
19] Trevissoi et al. 2024. Detection of butterfly fractures of long bones through multi-slice computed tomography and micro-computed tomography. Legal Medicine, 67, 102394.
20] Walden et al. 2023. Quantifying microcracks on fractured bone surfaces – Potential use in forensic anthropology. Journal of Mecidinal Behaviour of Biomedical Materials, 142, 105824.
21] Wang et al. 1998. An interspecies comparison of bone fracture properties. Biomechanical materials and Engineering, 8(1), pp. 1-9.
22] Yan et al. 2006. Application of fracture mechanics to failure in manatee rib bone. Journal of Biomechanical Engineering, 128, pp. 281-289.
